TERRA PC-BUSINESS 6500 | AMD Ryzen 7 5700G | 16GB RAM | 1TB SSD | Windows 11 Pro

'Build to Order'
‘Due in from 14/11/2025’

Rely on a PC that is fast, efficient and reliable - with the modern 7nm processor core technology at the heart of the system. The AMD Ryzen™ 5000 Series Desktop processor with Radeon™ graphics unit has been designed with the industry leading 7nm process of the "Zen2" processor technology was developed. This ensures faster, more efficient computing power that canfaster than ever before - and yet runs cool and quietly. You can be happy about1080p applications, without the need for an additional graphics card. In conjunction with the PCI-Express SSDyou a business PC with the most advanced technology.

General
Processor model	AMD Ryzen 7 5700G Processor (8C/16T, 16 MB L3 Cache, 4.6 GHz Boost)
Operating system	Windows 11 Pro
	Software
Pre-installed software	1 month trial version for new Microsoft® 365 user
	Processor
Processor family	AMD Ryzen 7
Processor cores	Okta-Core (8-Core)
Processor socket	AM4
Number of processors	1
	Memory
Internal memory	16 GB
Memory layout (slots x size)	2 x 8 GB
Maximum internal memory	128 GB
Memory clock speed	3200 MHz
Internal memory type	DDR4 SDRAM
Memory slots	4 pc(s)
Memory form factor	DIMM, 288-PIN
	Storage
Total storage capacity	1 TB
HDD interface	4x SATA-3 (6.0 Gb/s), 1x M.2 Socket 3, Type 2242/2260/2280 (S-ATA & PCIe x4 mode)
RAID levels	No Raid support
SSD interface	PCIe (NVMe) 3.0
SSD capacity	1 TB
HDD capacity	1 x 1 TB - SSD
Storage media	SSD M.2
	Performance
Series	Business
Product type	Personal-Computer
Noise level	22.6 dB(A) Operation office-mode w/o ODD running
Audio output channels	8-channel
Motherboard chipset	AMD A520
Audio system	High Definition Audio
	Design
Chassis type	Mini tower
Certification	ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC
Keyboard form factor	Option. Keyboard not included
	Keyboard
Keyboard language	Keyboard optional
Device interface	USB
	Technical details
Localization	International
	Packaging content
Included Accessories	Quick Start Guide, Powercord EU
Keyboard language	Option. Keyboard not included
	Expansion slots
Expansion slots	1 x PCIe 3.0 x16 (x16 mode), 1 x PCIe 3.0 x1
	Weight & dimensions
Height	37.5 cm
Width	18 cm
Depth	38.4 cm
Weight	7 kg
	Other features
Number of drive bays	1 front - 13.3 cm ( 5.25" ) 1 front - 8.9 cm ( 3.5" ) 1 internal - 8.9 cm ( 3.5"/ 2.5" with adapter)* 1 internal 6.4 cm (for 2.5" SSD) *Depending on production batch, installation basket for additional drives optional
Interface	1x PS/2, 1x DP, 1x HDMI, 1x RJ-45, 3x Audio, 4x USB 3.2 Gen1 Type-A (2x front), 2x USB 2.0
Compatible operating systems	Windows 10, Windows 11
Motherboard manufacturer	Gigabyte A520M DS3H V2
Cooling type	AMD Wraith Stealth CPU cooler
Compliance industry standards	This appliance is classified as a Class B information technology equipment (ITE) and is intended primarily for use in residential and office environments. The CE mark confirms conformity with the following EU directives: (1) EMC Directive 2004/108/EC Electromagnetic Compatibility (2) Low Voltage Directive 2006/95/EC Electrical equipment designed for use within certain voltage limits.
Special features	TPM 2.0 Secure Boot Windows Autopilot ready 2x USB 3.2 Gen1 Typ A + Audio in Front
	Mouse
Mouse included	TERRA Wheel optical by Cherry
	Graphics
On-board graphics adapter memory	Dynamic
On-board graphics adapter maximum resolution	HDMI max. 4096x2160 @ 60Hz, DP max. 5120x2880 @ 60 Hz
Graphics card	AMD Radeon™ Graphics 8-Core
On-board graphics card model	AMD Radeon™ Graphics 8-Core
Graphics adapter ports	1x HDMI, 1x Display Port (DP ) supports DualMonitoring
	Power
Power source	ATX power supply. Meets 80-plus Bronce Eligible for regular business use max. 60h/ week Energy efficiency (Workload 10 %/ 20 %/ 50 % / 100 %): 82 %/ 82 % / 85 % / 82 %
Power consumption (standby)	Ø 1.4 Watt (Sleep Mode S3, Suspend to RAM, WOL activated) 0,25 Watt Soft off (S5 Mode)
Maximum input power	400 W
Nominal power	Ø 16 Watt Long Idle-Mode Ø 68 kWh a year (TEC = Typical Energy Consumption) Further information regarding Energy consumption see https://www.wortmann.de/green and/ or Quicklinks for this product (if available)
AC adapter input voltage	AC 230V ( 50 Hz )
	Operational conditions
Operating temperature (T-T)	5 °C - 35 °C
Recommended humidity operating range	10 - 75% (non-condensing)
	Network
Ethernet LAN	Netzwerkadapter - integriert
LAN controller	Realtek RTL8118, WOL/ PXE
Data link protocols	Ethernet Fast Ethernet Gigabit Ethernet
	Optical drive
Optical drive type	DVD-Writer
	Input device
Movement detection technology	Optical
Device interface	USB Note: Keyboard not included
