‘Build to Order’
‘Due in from 5/12/2024’
General | |
Processor model | Intel Core i5 (14. Gen.) 14500 / max. Intel Turbo Boost Frequenzy 5.0 GHz, 24 MB Intel Smart Cache |
Operating system | Windows 11 Pro |
Software | |
Pre-installed software | 1 month trial version for new Microsoft® 365 user |
Display | |
Display resolution | 1920 x 1080 ( Full HD ) |
Display type | Non-Touch LCD-Display – Non Glare |
Display brightness | 250 cd/m2 |
Response time | 14 ms |
Contrast ratio (typical) | 1300:1 |
Viewing angle, horizontal | 178 |
Viewing angle, vertical | 178 |
LED backlighting type | LED-Backlight |
Display diagonal | 23.8″ |
Processor | |
Processor family | Core i5 |
Processor cores | 14 Core |
Maximum number of SMP processors | 1 |
Processor socket | FCLGA1700 (max. 65 Watt TDP) |
Motherboard chipset | Intel H610 Express |
Number of processors | 1 |
Memory | |
Internal memory | 16 GB |
Memory layout (slots x size) | 1x 16 GB |
Maximum internal memory | 64 GB |
Memory clock speed | 5600 MHz |
Internal memory type | DDR5 |
Memory slots | 2 |
Storage | |
Total storage capacity | 1 TB |
HDD interface | 2x S-ATA 6GB/s 1x M.2 type 2260/2280 (SATA & PCIe 4.0 x4 NVMe) |
RAID levels | No RAID supported No RAID supported |
SSD interface | PCIe (NVMe) |
SSD capacity | 1 TB |
HDD capacity | 1 x 1 TB – solid state |
Storage media | SSD M.2 |
Optical drive | |
Optical drive type | None |
Performance | |
Product type | Personal-Computer |
Noise level | 0,5 Sone |
Keyboard | |
Device interface | USB |
Technical details | |
Localization | International |
Packaging content | |
Included Accessories | Quick Start Guide, PSU, Powercord EU |
Keyboard supplied | Optional |
Weight & dimensions | |
Height | max.: 52.0 min.: 38.9 cm |
Width | 54.0 cm |
Depth | 5.4 Grundfläche Fuss: 25.4 x 24.3 (B x T) cm |
Weight | 7.5 kg |
Other features | |
Expansion slots | 1x 2.5″ SSD |
Interface | Right: 1x USB 3.2 Gen1, 1x USB 3.2 Gen1 Type-C Bottom: 1x HDMI 2.0, 1x DP 1.4 supports Triple-screen 1x RJ45, 2xUSB 2.0, 2x USB 3.2 Gen2, Line in/out, dc-in, Power Button |
Compatible operating systems | Windows 10, Windows 11 |
Maximum cooling capacity | Active |
Special features | Cam: 5m resolution 2x 3W Stereo Speaker Bluetooth Kensington-Lock High-adjustable 105 mm Pivot Function Swiveling -5°/ +20°VESA 100×100 mm Cam: 5m resolution 2x 3W Stereo Speaker Bluetooth Kensington-Lock High-adjustable 105 mm Pivot Function Swiveling -5°/ +20°VESA 100×100 mm |
Design | |
Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar 8.0, EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
Form factor | All-in-one |
Mouse | |
Mouse included | Optional |
Graphics | |
Maximum resolution | HDMI 2.1 max. 4096 x 2160, DP 1.4 max. 4096 x 2304 |
On-board graphics adapter memory | Dynamic |
Graphics card | Intel UHD Graphics 730 |
On-board graphics card model | Intel UHD Graphics |
Power | |
Power source | Power adapter |
Power consumption (standby) | Ø 2.0 Watt (S3 Mode, Suspend to RAM, WOL activated) |
Maximum input power | 120 Watt |
Nominal power | Ø 34,45 Watt Short Idle-Mode 115 kWh per Year (ETEC = Typical Energy Consumption) |
AC adapter input voltage | 100-240 V~ / 50-60 Hz |
Operational conditions | |
Operating temperature (T-T) | 5° C – 35° C |
Maximum operating temperature range (T-T) | 35 °C |
Recommended humidity operating range | 10 – 75% (non-condensing) |
Network | |
LAN controller | Realtek Gigabit LAN, WOL/ PXE |
Wi-Fi standards | Intel Dual Band Wireless-AX 201 Frequency band: 2.4 GHz + 5 GHz Dual Stream WiFi 6 (802.11ax) |
Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax Bluetooth 5.1 |
Input device | |
Device interface | USB |
Audio | |
Audio output channels | 8-channel |
Audio system | Integrated |
