‘Build to Order’
General | |
Processor model | Intel Core i5 (13. Gen.) 13500 / 24 MB Intel Smart Cache, max. 4.8 GHz Intel Turbo Boost Technology |
Operating system | Windows 11 Pro |
Processor | |
Processor family | Core i5 |
Processor socket | FCLGA1700 Socket |
Number of processors | 1 |
Memory | |
Internal memory | 16 GB |
Memory layout (slots x size) | 2 x 8 GB |
Maximum internal memory | 128 GB |
Memory clock speed | PC4800 MHz |
Internal memory type | DDR5 SDRAM |
Memory slots | 4 |
Memory form factor | DIMM, 288-PIN |
Storage | |
Total storage capacity | 512 GB |
RAID levels | RAID 0, 1, 5, 10 (No M.2 NVMe RAID support) RAID 1 RAID 5 RAID 10 |
Hybrid hard drive (H-HDD) capacity | 500 GB |
SSD interface | PCIe (NVMe) |
SSD capacity | 512 GB |
HDD capacity | 1 x 500 GB – SSD |
Number of storage drives supported | 6 |
Storage media | SSD M.2 |
Performance | |
Series | Medical |
Motherboard chipset | Intel B660 |
Design | |
Chassis type | Mini tower |
Keyboard form factor | Terra Logitech |
Keyboard | |
Keyboard language | German |
Connectivity technology | Wired |
Device interface | USB |
Technical details | |
Localization | Deutschland / Deutsch |
Packaging content | |
Included Accessories | Quick Install Guide, Multi-country AC adapter (IEC plug types A, C, G & I), VESA mounting Kit |
Weight & dimensions | |
Height | 37.5 cm |
Width | 18 cm |
Depth | 38.4 cm |
Weight | 7 kg |
Other features | |
Number of drive bays | 1 front – 13.3 cm ( 5.25″ ) 1 front – 8.9 cm ( 3.5″ ) 1 internal – 8.9 cm ( 3.5″/ 2.5″ with adapter)* 1 internal 6.4 cm (for 2.5″ SSD) *Depending on production batch, installation basket for additional drives optional |
Compatible operating systems | Windows 10, Windows 11 |
Cooling type | TERRA Silent CPU cooler (active) |
Compliance industry standards | CE, ISO 9001, Assembled in Germany Compatibility: PC2001, SMBios (DMI) 2.3, PCI 2.2,WFM 2.0, EnergyStar, EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
Mouse | |
Mouse included | Terra Logitech |
Graphics | |
On-board graphics adapter maximum resolution | VGA up to 2048×1536, DVI up to 1920×1200 (Single-Link), Display-Port up to 2560×1600 |
Graphics card | Intel UHD Graphics 770 |
On-board graphics card model | Intel UHD Graphics 770 |
Graphics adapter ports | 4x DisplayPort V1.4a |
Power | |
Power source | Power supply |
Maximum input power | 400 Watt |
AC adapter input voltage | 100-240 V~ / 50-60 Hz |
Network | |
Ethernet LAN | Network adapter – integrated |
LAN controller | Intel i219LM |
Optical drive | |
Optical drive type | Without optical drive |
Input device | |
Movement detection technology | Optical |
Device interface | USB |
